Description
Z50B.6C-12 planet gear changlin zl50h spare parts
1 Z50B.6-7 1 盖板 Cover 4
-5071689
1 Z50B.6-7A 盖板 Cover 4
5071689-
2 Z50B.6-6 1 密封垫 Washer 4
5071195-
3 B-G003080-00001 1 钢球 10.000-G100-b Ball 12
5071195-
4 Z50B.6-14 1 行星齿轮轴 Planet gear shaft 12
5071195-
5 Z50B.6C-1 1 行星轮架 Planet carrier 4
5071195-
6 Z50B.6-17 1 密封垫 Washer 4
5071195-
7 Z50B.6-13 1 垫片 Spacer 24
5071195-
8 Z50B.6C-12 1 行星齿轮 Planet gear 12
5071195-
9 B-G003090-00002 1 滚针 5×49.8 Needle roller 372
5071195-
10 Z50B.6-11 1 调整垫 Adjust washer 4
5071195-
11 Z50B.6-10 1 半轴定位堵 Locator 4
-5071689
11 Z50B.6-10A 1 半轴定位堵 Locator 4
5071689-
12 B-G001190-00015 1 销 A5×25 Pin 4
5071195-
13 Z50B.6-4 1 圆螺母 Nut 4
5071195-
14 Z50B.6C-8 1 太阳轮半轴 Half-shaft 4
5071195-
15 B-G057830-00034 1 螺栓 M12×30 ZnD Bolt 24
5071195-
16 B-G000930-00003 1 垫圈 12 Spring washer 24
5071195-
17 Z50B.6A-26 1 卡环 Snap ring 4
5071195-
18 B-G09877A-00017 1 油封 FB150×180×15 Oil seal 4
5071195-
19 B-J010000-00011 1 螺塞 M27×2 Plug 6
5071195-
20 Z50B.6-16 1 轮辋螺母 Rim nut 40
5071195-
21 B-J009820-00008 1 垫圈 27 Washer 8
5071195-
22 Z50B.6-15 1 轮辋螺栓 Rim bolt 40
5071195-
23 B-G000930-00008 1 垫圈 20 Spring washer 76
5071195-
24 B-G057820-00227 1 螺栓 M20×65-10.9ZnD Bolt 36
5071195-
25 B-G000700-00002 1 螺钉 M10×20 Screw 4
5071195-
26 B-G000930-00001 1 垫圈 10 Spring washer 4
5071195-
27 W-03-00023 1 通气塞 Breather 2
5071195-
28 Z50B.6C-2 1 内齿圈 Internal gear 4
5071195-
29 B-G002970-00024 1 轴承 32221 Bearing 4
5071195-
30 Z50E.6E-4 1 轮毂 Wheel hub 4
5071195-
32 Z50B.6-18 1 螺母 M20×1.5-6H Nut 40
5071195-
33 B-G002970-00017 1 轴承 32024 Bearing 4
5071195-
34 B-G057830-00058 1 螺栓 M14×40 ZnD Bolt 32
5071195-
35 B-G000930-00005 1 垫圈 14 Spring washer 32
5071195-
36 B-G001190-00005 1 销 A12×35 Pin 4
5071195-
37 Z50E.6E-5 1 制动盘 Brake disc 4
5071195-
38 B-Q020490-00009 1 垫圈 18 Washer 64
5071195-
39 W-18-00059 1 制动器总成|SOMA75700444F Washer 6
5071195-
40 B-G057850-00090 1 螺栓 M18×1.5×90-10.9 Bolt 64
5071195-
41
Z50E.8E-1
Z50E.8E-2
Z50E.6E-2
1
左轮边支承轴（前）
右轮边支承轴（前）
轮边支承轴（前）
Support shaft
1
1
2
5071195-
43 Z50B.6-22 1 螺栓 Bolt
前30
后22
5071195-
44 B-Q020490-00011 1 垫圈 20 Washer
前30
后22
5071195-
45 Z50B.8-3 1 密封垫 Gasket 2
5071195-
46
Z50B.6C-23
Z50B.8C-1
1
前桥壳
后桥壳
Front axle case
Rear axle case
1
1
5071195-
47 B-G008270-00004 1 钉 2×5 Pin 8
5071195-
48
Z50H.6A-24
Z50H.8A-2
1
标牌（前）
标牌（后）
Name plate
Name plate
1
1
5071195-
49 Z50B.6-28 1 密封垫 Gasket 2
5071195-
50 B-J010010-00006 1 螺塞 M27x2 Plug 2
5071195-
51 Z50B.6-25 1 密封垫 Gasket 2
5071195-
55 B-G001190-00008 1 销 A16x50 Pin 4
5071195-
56 B-Q020490-00017 1 垫圈 27 Washer 32
5071195-
57 B-G061710-00030 1 螺母 M27x2ZnD Nut 16
5071195-
58 B-G061730-00026 1 螺母 M27x2ZnD Nut 16
5071195-
59 B-G057850-00068 1 螺栓 M27x2x270-10.9ZnD Bolt 16
5071195-
