序号

No.

零 件 代 号

Part No.

版本

Ver.

名 称

Part Name

数量 Q’ty

适用车号

Suit Num.

选装

Cho

1

B-G094590-00003

1

螺母 M24×1.5 ZnD Nut

2

9570001-

2

Z50B.4.1-6

1

垫圈

Washer

2

9570001-

3

Z50E.4E.1-1

1

前法兰

Front flange

1

9570001-

4

B-G057830-00006

1

螺栓 M10×25 ZnD Bolt

6

9570001-

5

B-Q020710-00088

1

O 形密封圈 65×5.7 O-ring

2

9570001-

6

B-G000930-00001

1

垫圈 10

Spring washer

14

9570001-

7

Z50B.4.1-2

1

轴承盖

Bearing cover

2

9570001-

8

Z50B.4.1-3C

1

纸垫

Paper pad

2

9570001-

9

W-15-00115

1

AE3618A0(NOK)

Oil seal

2

9570001-

10

B-G002970-00019

1

滚动轴承 32212 Bearing

2

9570001-

11

Z50E.4C.1-1

1

齿轮

Output shaft gear

1

9570001-

12

B-G00894A-00023

1

挡圈 82

Retainer

1

9570001-

13

Z50E.4E.1-4

1

输出轴

Output shaft

1

9570001-

14

Z50E.4E.1-5

1

后法兰

Rear flange

1

9570001-

15

B-G000910-00049

1

开口销 5×45 ZnD Cotter pin

1

9570001-

16

B-G057830-00010

1

螺栓 M10×30 ZnD Bolt

8

9570001-

序号

No.

零 件 代 号

Part No.

版本

Ver.

名 称

Part Name

数量 Q’ty

适用车号

Suit Num.

选装

Cho

1

Z50B.4.4A-5

1

轴承盖

Bearing cover

1

9570001-

2

Z50B.4.2-19A

Z50B.4.2-19B

Z50B.4.2-19C

1

1

1

纸垫

纸垫

纸垫

Paper pad

Paper pad

Paper pad

4 组 4

4

9570001-

9570001-

9570001-

3

B-G00894A-00019

1

挡圈 55

Snap ring

2

9570001-

4

B-G002760-00032

1

轴承 6311

Bearing

2

9570001-

5

Z50B.4.2-2

1

垫环

Spacer ring

1

9570001-

6

Z50E.4C.2-1

1

输出齿轮

Output gear

1

9570001-

7

Z50B.4.2-25

1

轴套

Bushing

1

9570001-

8

B-G002760-00010

1

轴承 6013

Bearing

2

9570001-

9

Z50E.4.2-2

1

齿轮

Gear

1

9570001-

10

Z50B.4.2-14

1

垫环

Spacer ring

1

9570001-

11

Z50B.4.2-11

1

卡环

Snap ring

4

9570001-

12

Z50B.4.3-4

1

一挡压盖

1st and 2nd cover

1

9570001-

13

Z50B.4.2-7

1

主动摩擦片

Drive disc

20

9570001-

14

Z50B.4.2-8

1

从动摩擦片

Driven disc

18

9570001-

15

Z50B.4.2-15

1

波形弹簧

Wave spring

36

9570001-

16

Z50B.4.2-12

1

活塞

Piston

2

9570001-

17

Z50B.4.2-23

1

挡圈

Snap ring

8

9570001-

18

Z50B.4.2-24

1

矩形密封圈

Seal ring

2

9570001-

19

Z50B.4.2-13

1

缸体

Cylinder body

1

9570001-

20

Z50B.4.2-5

1

齿圈

Gear ring

1

9570001-

21

Z50B.4.2-10

1

活塞回位弹簧 Retraction spring

8

9570001-

22

Z50B.4.2-9

1

活塞回位拉杆 Retraction drag rod

8

9570001-

23

B-G057830-00010

1

螺栓 M10×30 ZnD Bolt

12

9570001-

24

B-G000930-00001

1

垫圈 10

Spring washer

12

9570001-

25

Z50B.4.2-22

1

压盖

Cover

1

9570001-

26

Z50B.4.2-21

1

轴

Shaft

1

9570001-

27

Z30.4.1-19

1

油封环

Oil seal ring

4

9570001-

28

B-G000780-00006

1

螺钉M12×12

Screw

2

9570001-

29

Z50B.4.2-16

1

轴承垫

Bearing washer

1

9570001-

30

B-G002760-00009

1

轴承 6012

Bearing

1

9570001-

31

Z50E.4.2-3

1

齿轮

Gear

1

9570001-

32

B-G002760-00008

1

轴承 6011

Bearing

1

9570001-

33

Z50B.4.2-18

1

轴套

Bushing

1

9570001-

34

Z50B.4.2-20

1

轴承盖

Bearing cover

1

9570001-

序号

No.

零 件 代 号

Part No.

版本

Ver.

名 称

Part Name

数量 Q’ty

适用车号

Suit Num.

选装

Cho

1

Z50B.4.3A-1

1

轴承盖

Bearing cover

1

9570001-

2

B-G00894A-00019

1

挡圈 55

Snap ring

2

9570001-

3

W-03-00067

1

轴承 6311(SKF)

Bearing

1

9570001-

4

Z50B.4.2-2

1

垫环

Spacer ring

1

9570001-

5

Z50E.4C.3-1

1

输出齿轮

Output gear

1

9570001-

6

Z50B.4.3-2

1

轴套

Bushing

1

9570001-

7

B-G002760-00010

1

滚动轴承 6013

Bearing

2

9570001-

8

Z50E.4.3-2

1

齿轮

Gear

1

9570001-

9

Z50B.4.2-14

1

垫环

Spacer ring

1

9570001-

10

Z50B.4.2-6

1

螺塞

Plug

1

9570001-

11

Z50E.4.3-5

1

轴

Shaft

1

9570001-

12

B-G057830-00010

1

螺栓 M10×30 ZnD Bolt

12

9570001-

13

B-G000930-00001

1

垫圈 10

Washer

12

9570001-

14

Z50B.4.2-11

1

卡环

Snap ring

3

9570001-

15

Z50B.4.3-5

1

齿圈

Gear ring

1

9570001-

16

Z50B.4.3-4

1

一挡压盖

1st cover

1

9570001-

17

Z50B.4.2-7

1

主动摩擦片

Drive disc

14

9570001-

18

Z50B.4.2-8

1

从动摩擦片

Driven disc

13

9570001-

19

Z50B.4.2-15

1

波形弹簧

Wave spring

26

9570001-

20

Z50B.4.2-12

1

活塞

Piston

1

9570001-

21

Z50B.4.2-23

1

挡圈

Retainer

4

9570001-

22

Z50B.4.2-24

1

矩形密封圈

Seal ring

1

9570001-

23

Z50E.4.3-3

1

缸体

Cylinder body

1

9570001-

24

Z50B.4.2-10

1

活塞回位弹簧 Retraction spring

4

9570001-

25

Z50B.4.2-9

1

活塞回位拉杆 Retraction drag rod

4

9570001-

26

Z30.4.1-19

1

油封环

Oil seal ring

9570001-

27

B-G000780-00006

1

螺钉M12×12

Screw

1

9570001-

28

Z50E.4.3-4

1

隔套

Collar

1

9570001-

29

Z50B.4.2-19A

Z50B.4.2-19B

Z50B.4.2-19C

1

1

1

纸垫

纸垫

纸垫

Paper pad

Paper pad

Paper pad

2 组 2

2

9570001-

9570001-

9570001-

30

Z50B.4.3-7

1

轴承盖

Bearing cover

1

9570001-

31

W-03-00050

1

轴承 6411(SKF) Bearing cover

1

9570001-

32

Z50B.4.3A-4A

Z50B.4.3A-4B

Z50B.4.3A-4C

1

1

1

纸垫

纸垫

纸垫

Paper pad

Paper pad

Paper pad

2 组 2 2

9570001-

9570001-

9570001-
