序号

No.

零
件
代
号

Part No.

名
称

Part Name

数量

Q’ty

1

2

3

4

5

7

8

9

10

11

12

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

B-J07940A-00001

B-G057830-00066

B-Q01201E-00003

Z50B.12.13A

B-Q01201C-00008

Z50B.12B.2

B-G00097B-00004

B-G057830-00028

B-G000930-00003

Z50B.12.1A

B-G057820-00144

B-G00097B-00014

B-G000930-00010

B-G061700-00023

Z50E.32.1

B-G057830-00066

B-Q01201E-00003

Z50E.12Q.2

B-G000730-00003

Z50B.12-11

B-G057830-00043

B-G000930-00003

B-G10708C-00006

Z50B.12-2

B-G091630-00007

Z50B.12A-5

Z50E.12Q-1

B-G10708C-00007

油杯 M10×1            Grease fitting

螺栓 M16×25 ZnD        Bolt

垫圈 16                Washer

上铰销组件             Upper hinge pin assembly

垫片 97×150            Pad

铰销组件 95×280A        Hunger pin assembly

垫圈    12ZnD            Washer

螺栓 M12×20 ZnD        Bolt

垫圈 12                Washer

前盖板                 Front cover

螺栓M24×280-10.9ZnD    Bolt

垫圈 24ZnD             Washer

垫圈 24                Washer

螺母 M24 ZnD            Nut

前车架                 Front frame

螺栓 M16×25 ZnD        Bolt

垫圈 16                Washer

上铰接轴                Upper hinge shaft

螺钉 M6×8             Screw

轴套                    Bushing

螺栓 M12×45 ZnD        Bolt

垫圈 12                Washer

骨架防尘圈 FB80×90×7    Dust ring

上轴承盖                Upper bearing cover

关节轴承 GE80ES        Joint bearing

上轴承座                Upper bearing seat

下铰接轴                Lower hinge shaft

骨架防尘圈 FB90×100×7    Dust ring

11

5

5

2

4

1

4

8

4

1

16

48

24

48

1

1

1

1

8

2

24

24

2

1

2

1

1

2

序号

No.

零
件
代
号

Part No.

名
称

Part Name

数量

Q’ty

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

Z50B.12-6

Z50B.12A-4

Z50E.12Q-3

Z50E.12Q-2

B-Q020490-00003

B-G057820-00042

Z50E.12Q-7

B-G000910-00068

B-Q01201E-00001

Z50B.12B.3

Z50B.12-9

Z50B.12.12A

B-G057830-00057

B-G000930-00005

Z50B.12.2E.2

Z50E.12Q-4

Z50E.12Q-5

Z50E.12Q-6

下轴承盖                Lower hinge shaft

下轴承座                Lower bearing cover

轴套                    Bushing

板                     Plate

垫圈 12                Washer

螺栓 M12×55 10.9 ZnD    Bolt

槽形螺母                Castle nut

销 8×90 ZnD            Pin

垫圈 12                Washer

铰销组件 40×132A        Hinge pin assembly

支架垫                 Pad

下铰销组件              Lower hinge assembly

螺栓 M14×35 ZnD        Bolt

垫圈 14         Washer

板                     Plate

调整垫片 t0.5            Adjusting shim

调整垫片 t1             Adjusting shim

调整垫片 t0.2            Adjusting shim

1

1

1

1

8

8

1

1

4

2

2

2

2

2

1

4

2

4

序号

No.

零
件
代
号

Part No.

名
称

Part Name

数量

Q’ty

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

Z50E.12U.1

Z50E.12F.6B

Z50E.12F.5B

Z50E.12F-1

B-Q020490-00011

B-G057830-00100

Z50E.12F.5.2

Z50E.12F.5-1

B-G061700-00003

Z50E.12V.1

Z50F.12.2

Z50F.12-2

Z50F.12-1

Z50B.12-10

Z50B.12B.3

Z50B.12.15

Z50B.12.16

Z50B.12A.3

Z50B.12.14

B-G000930-00003

B-G057830-00030

B-Q020490-00015

B-G057820-00150

Z50F.12.3

后车架                Rear frame

右电瓶箱            Right battery box

左电瓶箱            Left battery box

护套                Rubber ring

垫圈 20            Washer

螺栓 M20×55 ZnD    Bolt

压框                Pressed frame

螺栓杆                Screw

螺母 M10 ZnD        Nut

配重                Balance weight

摆架                balanced frame

压板             Plate

摆架销轴            Axis pin

摆架轴套            Bushing

铰销组件 40×132A    Hinge pin

销                    Pin

保险销                Locking pin

车架锁                Frame pin

销                    Pin

垫圈 12            Washer

螺栓 M12×25 ZnD    Bolt

垫圈 24 Washer24

螺栓 M24×80-10.9 ZnD Bolt

气室支架 Chamber support

1

1

1

4

8

8

2

4

16

1

1

4

2

2

2

1

1

1

1

8

8

5

5

1
